UMA / PRODUCTS / Lens MTF Tester
DSC-502F
1
DSC-502F
Lens MTF Tester
DSC-502F adopts the front projection optical mechanism by using Relay lens and Collimators for Lens MTF inspection.
APPLICATION
Macro lens applications, such as in-display fingerprint recognition, endoscope camera, and cell phone macro camera.
The lens of NB, cellphone, surveillance system, automotive, etc.
FEATURES
✔ The optical system supports micro distance (1mm~35mm) measurement and other customized requirements.
✔ The optical system supports finite and infinity object distances measurement, of which the shortest object distance is 20cm.
✔ With the standard Relay Lens, the Cover Glass limitation and back focal length problem in the front projection mechanism are solved.
✔ There is no concern about exceeding the minimum Reticle design size and collision risks when the reticle needs to move deep into the tray and lens
✔ Apart from the macro lens, though the Test Chart might be replaced based on the client’s product specification, the Reticle does not need to be replaced when changing sample type.
✔ For adding test points in the finite or infinity object distance mechanism, the user only needs to purchase required Collimators and lenses.
✔ Support complete optical test items.
Lens MTF Tester
DSC-502F adopts the front projection optical mechanism by using Relay lens and Collimators for Lens MTF inspection.
APPLICATION
Macro lens applications, such as in-display fingerprint recognition, endoscope camera, and cell phone macro camera.
The lens of NB, cellphone, surveillance system, automotive, etc.
FEATURES
✔ The optical system supports micro distance (1mm~35mm) measurement and other customized requirements.
✔ The optical system supports finite and infinity object distances measurement, of which the shortest object distance is 20cm.
✔ With the standard Relay Lens, the Cover Glass limitation and back focal length problem in the front projection mechanism are solved.
✔ There is no concern about exceeding the minimum Reticle design size and collision risks when the reticle needs to move deep into the tray and lens
✔ Apart from the macro lens, though the Test Chart might be replaced based on the client’s product specification, the Reticle does not need to be replaced when changing sample type.
✔ For adding test points in the finite or infinity object distance mechanism, the user only needs to purchase required Collimators and lenses.
✔ Support complete optical test items.
2
FUNCTIONS
✔ MTF
✔ DOF
✔ FBL
✔ EFL
✔ Through Focus
✔ Focus Tilt
✔ S.F.R
✔ Tilt Angle
✔ Image Plane Correction
✔ Limit Resolution
✔ Optical Distortion
✔ MTF
✔ DOF
✔ FBL
✔ EFL
✔ Through Focus
✔ Focus Tilt
✔ S.F.R
✔ Tilt Angle
✔ Image Plane Correction
✔ Limit Resolution
✔ Optical Distortion
3
SPECIFICATIONS
| Machine Dimensions(cm) | 142cm *76cm *160cm |
| Machine Weight(Kg) | 250 Kg |
| Power Supply | AC220V/10A |
| IPC Operation system | Microsoft Windows 10 |
| MTF Repeatability (10pcs sample、tray in/out 5 times、 excluding load & unload) |
Delta MTF： On axis <=1.5 ；off axis <=2.5 |
| Average test times/pc depend on test item and FBFL deviation (without tray load and unload) |
2.5s/pc (M6 Lens) |
| Maximum Measuring Frequency | 200lp/mm |
| Min. FBL | > -1.5mm |
| Measured Lens Limit | Max. Image Height (Diagonal) =2.4mm (1/3inch*0.8f) |
