MD-60AA Pro T
1
MD-60AA Pro T
High Precision Camera Module Active Alignment System
MD-60AA Pro T Type provides full-function, automatic, and high precision active alignment capability for a vary-focus camera module.
Through 6-degree freedom adjustment based on image plane calculation of wide and tele mode, the image quality of the vary-focus camera module is effectively improved.
APLLICATION
The vary-focus camera module.
FEATURES
✔ Full-function and digitalized Lens image quality alignment. Optimize image quality by 6-degree freedom adjustment.
✔ Support vary-focus camera modules that satisfy the image quality balance between wide and tele requirements.
✔ High speed image tilt alignment. Able to proceed promptly and accurately image plane correction by αβ axis adjustment and through focus curve calculation.
✔ Quick model change designed tray and jig. Active alignment part can work alone with other accessary module for mass production.
✔ The system also can be designed by following client’s requirements of production line.
✔ Up to 4 ~ 8 UV wands design for large curing area requirement.
Series Type
► MD-60AA
► MD-60AA Pro
► MD-60AA HX
► MD-60AA Pro T
► MD-60AA Compact
High Precision Camera Module Active Alignment System
MD-60AA Pro T Type provides full-function, automatic, and high precision active alignment capability for a vary-focus camera module.
Through 6-degree freedom adjustment based on image plane calculation of wide and tele mode, the image quality of the vary-focus camera module is effectively improved.
APLLICATION
The vary-focus camera module.
FEATURES
✔ Full-function and digitalized Lens image quality alignment. Optimize image quality by 6-degree freedom adjustment.
✔ Support vary-focus camera modules that satisfy the image quality balance between wide and tele requirements.
✔ High speed image tilt alignment. Able to proceed promptly and accurately image plane correction by αβ axis adjustment and through focus curve calculation.
✔ Quick model change designed tray and jig. Active alignment part can work alone with other accessary module for mass production.
✔ The system also can be designed by following client’s requirements of production line.
✔ Up to 4 ~ 8 UV wands design for large curing area requirement.
Series Type
► MD-60AA
► MD-60AA Pro
► MD-60AA HX
► MD-60AA Pro T
► MD-60AA Compact
2
FUNCTIONS
| Optical Set Up | Infinity-Finite Projection |
| Active Alignment | 6 axis alignment to get the best image quality |
| UV Pre Cure | 4~8 LED head UV pre-cure |
| Through Focus and SFR Curves | Before and after Active Alignment |
| MTF and Decenter Test | MTF test before and after pre-cure |
3
SPECIFICATIONS
| Machine Dimensions | 1500mm(D)*1200mm(W)*2000mm(H) |
| Machine Weight | 450KG |
| Power Supply | AC220V/10A |
| Communication Interface | I/O Card |
| Software Operation | Windows 10 |
| Discerption | Sequential Process 6 axis adjustment for Sensor Board |
| Optical System | Back illuminated film chart with object distance adjustable relay lens system |
| Module Dimensions Limitation | • Lens ：~50 mm(W) X 50 mm (L) X 150 mm(H) • PCB Board：~50 mm(W) X 50 mm (L) Note. Lager size parts may need a customized system, which required evaluation by UMA. |
| XYZαβθ Axis SPEC Stroke/resolution (θ Axis is option) |
• X Axis：20mm/0.001mm • Y Axis：320mm/0.001mm • Z Axis：40mm/0.0004mm • α Axis：3 ˚ /0.0045 ˚ • β Axis：3 ˚ /0.0035 ˚ • θ Axis：± 5 ˚ / 0.0042 ˚ |
| UPH (Depends on product) | ~30 pc/hr (UV curing time=10secs, Frame rate=20, wide/tele balance loop 1 time) |
